Giuliano Santagata & C

NTN 4T32004X bearing

NTN 4T32004X bearing

Regular price €10,90
Regular price Sale price €10,90
Sale Sold out
Tax included. Shipping calculated at checkout.

Tax calculated at checkout

Tapered roller bearing, sheet metal cage

The single row tapered roller bearing is available in metric (ISO 355 and JIS B 1512 standards) and inch (ABMA standard, including J metric series) sizes. The single row version in the range of tapered roller bearings is the most commonly used and is usually mounted opposite another similar bearing.

Technical specifications:

Brand name nt extension
d - Inner diameter 20mm
D - Outside diameter 42mm
B - Bearing/inner ring width 15mm
C - outer ring width 12mm
T - Total width 15mm
d1 - Outer diameter Inner ring 31mm
a - Load Application point position 10.5mm
rs - Minimum radius of the Fillet 0.6mm
r1s - Minimum radius of the Fillet 0.6mm
Weight 0.097kg
ISO355 designation T3CC020

Shipping and Returns

The product will be delivered to the address indicated at the time of order confirmation.

The delivery times expressed on the site are indicative and depend on the products chosen and can be modified at any time and are not to be considered binding in any way, even if our firm intention is to process each order as quickly as possible, generally 48h.

We remind you that in the same order it is possible to insert different products but in the case of the presence of multiple different products it could be required a few more days for the evasion.

Shipments are made with GLS Express Courier within 24/48 hours (islands excluded); for the islands the estimated time is 48/72 hours.

Upon delivery of the goods, the Customer is required to check:

  • that the number of packages delivered corresponds to what is indicated in the transport document.
  • that the packaging is intact and not altered even in the closing tapes.

Shipping takes place within 24/48 hours of receipt of payment. Any possible delay by the express courier is not to be charged to Giuliano Santagata & C. sas.

Both the bank transfer and the money order take 3-5 days to arrive. The products will be shipped only when we receive the real credit on the c/c.

In the event of tampering and/or breakage, the Customer must immediately dispute the shipment and/or delivery by writing "GOODS CONTROL RESERVE" on the signed copy of the delivery document to be returned to the courier or other operator.

The Customer is required to report any damage within 10 (ten) days of receipt of the goods, by registered mail in advance by fax or by mail to the following addresses:

For each delivery order, the Customer is required to specify at least one telephone number to allow the express courier to contact him in the event of delivery difficulties; if the delivery is not successful for reasons not attributable to Giuliano Santagata & C. sas or to the express courier for 2 consecutive passages, the costs of custody or redelivery will be charged as quantified by the express courier or it will be possible to collect the product at the courier sorting point.
View full details
